PL-5 HP Pro-Line Single to 3-Phase Rotary Phase Converter

Name: PL-5 HP Pro-Line Single to 3-Phase Rotary Phase Converter
SKU: PL-05-1-0
Price: 698.00 USD
Availability: InStock

NAPCco PL-5 Pro-Line 5kVA rotary phase converter with ODP idler motor and control panel

Single phase input power block with L1 and L2 terminal connections inside a NAPCco rotary phase converter

PL-5 Pro-Line – 5 HP Rotary Phase Converter

$698.00

The PL-5 is a CNC-rated, general-purpose rotary phase converter designed to take typical single-phase service and supply full running current to three-phase equipment.

What’s Included with the Pro-Line PL-5 HP rotary phase converter

Control Panel
- NEMA 1 Enclosure (Indoor)
- Built-in Motor Starter
- Digitally Controlled and Protected Start Circuit
- Pre-Wired and Ready to Install
- 10-Year Parts Warranty/ Lifetime Labor Warranty
ABB-Baldor Electric 5 HP Custom-Made Idler Motor
- ODP (Open Drip Proof) – Indoor Rated
- Soft Start
- Copper Windings
Fast Flat-rate UPS/FedEx Ground Shipping: $59 to anywhere in the lower 48
Financing Available: Click here to apply online in minutes
5 HP Phase Converter Stock Status: In stock

(Download PL-5 Spec Sheet PDF)

SKU: PL-05-1-0 Category: Pro-Line

Description
Additional information

Description

PL-5 BEST SIZED FOR: pl5
Recommended Starting Load: 2.5 HP
Recommended 3-Phase FLA Sizing: 7 Amps
Total Combined Load: Please Call for Sizing (877) 545-2926

What Can the PL-5 Power?

Easy Motor Loads up to 3 HP: Table Saw, Drill Press, Milling Machine

Medium Loads up to 2.5 HP: Belt Sander, Grinder, Mixer

Hard Loads up to 2.0 HP: Gearhead Lathe, Dust Collector, Fans

Very Hard Loads up to 1.5 HP (Consider Smart-Boost™): Air-Compressor, Submersible Pump

CNC and Resistive Loads up to 7 Amps

PL-5 SPECS (Download Spec Sheet): pl5 ul-5 ul5
Minimum Single Phase Input Circuit: 20 Amps
Single Phase Input Voltage: 208 – 250 Volts
3 Phase Output Voltage: 208 – 250 (Based on Input)
Voltage Balance: 2 – 5%
Idler Motor HP Size: 5 HP
NAPCco Model Number: PL-5

Additional information

Weight	89 lbs
Dimensions	18 × 12 × 8 in
Series	Pro-Line
HP Rating	5 HP
Recommended Load (HP)	2.5 HP
Recommended Load (Amps)	7 A
Input Voltage	208-250 V
Output Voltage	208-250 V
Recommended Breaker	20 A
Output Amperage	14 A
Product Origin	USA
